6.2.3 Setup Menu
 Digital Outputs (X4.1) 1of3
Output5 Node: System
Output5 Signal: Off
Output6 Node: System
Output6 Signal: Off
Output7 Node: System
Output7 Signal:
Off
 Digital Outputs (X4.1) 2of3
Output8 Node: System
Output8 Signal: Off
Output9 Node: System
Output9 Signal: Off
Output10 Node: System
Output10 Signal:
Off
 Digital Outputs (X4.1) 3of3
Output11 Node: System
Output11 Signal: Off
Output12 Node: System
Output12 Signal: Off
Output13 Node: System
Output13 Signal:
Off
 Digital Outputs (X4.2) 1of3
Output14 Node: System
Output14 Signal: Off
Output15 Node: System
Output15 Signal: Off
Output16 Node: System
Output16 Signal:
Off
 Digital Outputs (X4.2) 2of3
Output17 Node: System
Output17 Signal: Off
Output18 Node: System
Output18 Signal: Off
Output19 Node: System
Output19 Signal:
Off
 Digital Outputs (X4.2) 3of3
Output20 Node: System
Output20 Signal: Off
Output21 Node: System
Output21 Signal: Off
Output22 Node: System
Output22 Signal:
Off
If your instrument features optional digital I/O
boards, similiar menu pages for the additional
digital outputs are unlocked. The options for
each output are as described before.:
Menu pages 4 ... 6 (titled 'Digital outputs
(X4.1)') enable to congure outputs 5 ... 13 on
the rst expansion board ('X4.1' in the menu
title refers to the instrument´s I/O connector
X4.1).
Menu pages 7 ... 9 (titled 'Digital outputs
(X4.2)') enable to congure outputs 14 ...
22 on the second expansion board ('X4.2' in
the menu title refers to the instrument´s I/O
connector X4.2).
