Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG6-76
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
Adjust Conversion Input1
Mode: 0..20mA
ADC Output 8388608
Input Normalized to 0...1
Coeff a0: 1
Coeff a1: 2
Coeff a2: 3
Calc. Input Value 1013
Status Good
Select the type of signal, provided by the
external source.
Available options:
0..10V, 0..1V, 0..20mA: voltage or current
signal is applied
Off: Input is switched off
Test: the instrument internally generates a
step-like signal for testing purposes.
Enter the coefcients for your input signal
here, considering
- it is for a cubic equation max.
- it is normalized to 0...1 (see note in menu)
Shows the internal ADC output (informative)
Shows the calculated input value, based on
the coefcients a0..a2, for comparison with
the real input value. If both do not match,
correct the coefcients.
Input signal status.
Possible values:
Absent, Failure, Good, Simulated (e.g.
when in test mode)
6.2.3 Setup Menu
6.2.3.4.5.1.1 Adjust Conversion
Setup..
In-/Outputs..
Analog Inputs..
Analog Input1 ... 2
Adjust Conversion..
