Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 6-115
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
6.2.4 Status Menu
6.2.4.5.3 Status Menu Pressure Sensors
6.2.4.5.4 Status Menu Flow Sensors
Status..
Measurement..
Pressure Sensors..
Status..
Measurement..
Flow Sensors..
Pressure Sensors
DSP-P1 1090 hPa
Status Installed
DSP-P2 0 hPa
Status Absent
AIN1 0 hPa
Status Absent
AIN2 0 hPa
Status Absent
Ch1
Flow Sensors 1of2
DSP-F1 0.0 l/min
Status Installed
DSP-F2 0.0 l/min
Status Absent
DSP-F3 0.0 l/min
Status Absent
DSP-F4 0.0 l/min
Status
Absent
Ch1
 Flow Sensors 2of2
AIN1 0.0 l/min
Status Installed
AIN2 0.0 l/min
Status Absent
View data for all possibly installed pressure
sensors, provided in two lines each:
Each rst line shows the pressure sensor and
the currently measured value, followed by a
related line showing the sensor status:
View data for all possibly installed ow sen-
sors, provided in two lines each:
Each rst line shows the ow sensor and
the currently measured value, followed by a
related line showing the sensor status:
Sensor (possible values: DSP-P1, DSP-P2,
AIN1, AIN2) and current pressure.
Sensor (possible values: DSP-F1 ... -F4,
AIN1, AIN2) and current ow.
Sensor status
Possible values: Installed, Absent, Failure.
Sensor status
Possible values: Installed, Absent, Failure.
