6.2.4 Status Menu
6.2.4.5.1.2 Status Menu Secondary Variables
6.2.4.5.2 Status Menu Temperature Sensors
Status..
Measurement..
Component..
Secondary Variables..
Ch1
Temperature 40.0 °C
Temp Status Good
TempZComp 0.0 °C
TempSComp 0.0 °C
Pressure 1013 hPa
Pressure Status Good
Flow 1.1 l/min
Flow Status Good
Source Current
Status..
Measurement..
Temperature Sensors..
Ch1
Temperature Sensors 1of2
DSP-T1 40.0 °C
Status Installed
DSP-T2 0.0 °C
Status Absent
DSP-T3 0.0 °C
Status Absent
DSP-T4 0.0 °C
Status
Abset
Ch1
Temperature Sensors 2of2
AIN1 20.0 °C
Status Installed
AIN2 0.0 °C
Status Absent
This menu page provides some secondary
measurement data for the selected compo-
nent:
• Temperature, pressure and ow values
• Status of the related sensors
• Reference temperature for temperature
compensation, separately for zero and
span
View data for all possibly installed tempera-
ture sensors, provided in two lines each:
Each rst line shows the temperature sensor
and the currently measured value, followed by
a related line showing the sensor status:
Sensor (possible values: DSP-T1 ... -T4,
AIN1, AIN2) and current temperature.
Sensor status
Possible values: Installed, Absent, Failure.
Possible status values:
Good, Simulated, Failure, Absent
If the analyzer features an IR measurement,
this line shows the IR source current.
