7.4.1 Preparing a Calibration
Now open the next menu to assign up to 4
span gas valves to the selected channel: one
for each range.
Note!
Depending on the gas analyzer and SHS
conguration, is may be possible to assign a
specic valve to multiple ranges.
Again, don´t forget to specify the individual
purge times.
On the 3
rd
menu page, assign a blowback val-
ve for the selected channel, if such is installed.
Ch1
 Valve assignment 2of3
Span1 valve: V1
Purge time: 1 s
Span2 valve: None
Purge time: 0 s
Span3 valve: None
Purge time: 0 s
Span4 valve: None
Purge time:
0 s
Ch1
 Valve assignment 3of3
Blowback valve: None
Purge time: 0 s
Multi-channel unit:
On menu 1, press left to open SELECT
COMPONENT to change the settings for a
different channel.
Note!
To check, if entries, made on menu pages 2
& 3 are correct, go back to menu 1 and check
"Correct assign".
