Emerson Process Management GmbH & Co. OHG 7-19
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
7
Maintenance & Procedures
7.4.2 Manual Calibration
The next lines show
the calibration gas setup (here: required
zero gas concentration is 0.000 ppm),
the currently measured gas concentration
and the current gas ow.
"Status.." opens a new screen with enhanced
calibration information about the current chan-
nel (indicated in the uppermost display line).
"Results.." opens a new screen with results
of earlier calibrations (see left side).
Within this screen, "Deviations.." enables to
open another screen, showing the last and
and the summary of all deviations of earlier
calibrations.
When nished press
left several times to
return to either
SELECT COMPONENT (multi channel ana-
lyzer only), to perform a zero calibration for
another channel,
or
to CONTROL, where you may start a span
calibration. The procedure and screens look
similiar to those of a zero calibration:
Deviations
ZeroDev. 0.000 ppm
ZeroDev. total 0.000 ppm
SpanDev. 0.000 ppm
SpanDev. total 0.000 ppm
Ch1
Calibration results single
Zero result Success
Zero date 31/10/2012
Soan result Success
Span date 31/10/2012-
Calibr. ranges None
Deviations..
Ch1
Calibration status single
Cancel!
Calibr.status Ready
Remaining time 0 s
Concentration 0.000 ppm
Zero gas 0.000 ppm
Span gas 5000.000 ppm
Current range Range 1
Applied gas Sample gas
