Emerson Process Management GmbH & Co. OHG7-20
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
7.4.2 Manual Calibration
When nished, press
left several times to re-
turn to SELECT COMPONENT (multi channel
analyzer only), to perform a span calibration
for another channel,
or
press home to return to the MEASUREMENT
SCREEN, to nish with manual calibration
procedures.
7.4.2.2 Manual Span Calibration
Multi-channel unit:
Select the channel to be calibrated in
SELECT COMPONENT.
Before selecting any further line
make sure the required calibra-
tion gas is applied and owing!
Span calibration offers the same options as
Zero calibration, so for a detailled description
7-17.
Select "Span calibration.."
Span calibration
Cancel!
Start!
Span gas 0.000 ppm
Concentration 0.000 ppm
Flow 0.00 l/min
Status..
Results..
Restore!
Zero calibration..
Span calibration..
Advanced calibration..
Apply gas..
Lock menus!
Acknowledgements
Pump 1: Off
Pump 2: Off
Ranges..
