Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG7-32
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
7.4.3 Advanced Calibration
A sequence is executed step (action) by step
until
• it reaches an action END-OF-PRGM,
or
• "Action30" has been executed, after which
the sequence quits automatically.
Example
The channels of an analyzer are to be cali-
brated in the following order:
All
:
(Action1) Zero calibration
Channel 1:
(Action2) Span gas calibration
Channel2:
(Action3) Blowback
(Action4) Span gas calibration
Channel3:
(Action5) Span gas calibration range1
(Action6) Span gas calibration range3
... (Action7) End of program sequence
Program Sequence 1of8
Action1: Zero-Cal
Node1: All
Action2: SpanCal
Node2: Ch1
Action3: Blowback
Node3: Ch2
Action4: SpanCal
Node4:
Ch2
 Program Sequence 2of8
Action5: Rg1SpanCal
Node5: Ch3
Action6: Rg3SpanCal
Node6: Ch3
Action7: END-OF-PGRM
Node7: All
Action8: END-OF-PGRM
Node8:
All
