Emerson Process Management GmbH & Co. OHG 7-31
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
7
Maintenance & Procedures
7.4.3 Advanced Calibration
7.4.3.4 Calibrating With Sequence Programming
Setup..
Calibration..
Program Sequence..
...
Program Sequence 4of8
Action13: END-OF-PGRM
Node13: All
Action14: END-OF-PGRM
Node14: All
Action15: END-OF-PGRM
Node15: All
Action16: END-OF-PGRM
Node16:
All
Program Sequence 8of8
Action29: END-OF-PGRM
Node29: All
Action30: END-OF-PGRM
Node30: All
Page 1
Page 4
Page 8
Program Sequence 1of8
Action1: Zero-Cal
Node1: All
Action2: Rg1SpanCal
Node2: Ch1
Action3: Rg2SpanCal
Node3: Ch3
Action4: END-OF-PGRM
Node4:
All
This menu with 8 pages allows to setup a
sequences of up to 30 actions (steps), to
carry out individual calibration procedures.
Each step consists of an action and a related
node (channel).
Available actions are:
Action name What to happen
Rg1SpanCal ...
Rg4SpanCal
span calibrate range1
... range4
ZSpanCal zero & span calibrate
SpanCal span calibrate
ZeroCal zero calibrate
NoOp no action
Blowback start blowback
END-OF-PGRM end of programmed
sequence
Available nodes are (depending on number
of channels installed within your analyzer):
Node name
Selected action is
carried out for
All all installed channels
Ch1 ... Ch5
(depending on the
analyzer setup, an
assigned component
tag may show here
instead;
6-99
the selected channel
only
Program sequences enable to carry out
complex calibration procedures with up to
30 steps. A requirement to setup a sequence
is, that “Valves” in INSTALLED OPTIONS is
set to a value other than none (
6-88 )
.
Once this condition is fullled, a sequence
can be setup in SETUP - CALIBRATION -
PROGRAM SQEUENCE.
