Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG9-6
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Service.Calibration.ChanProcMode3 3313 3313 Word R/W
cal proc mode comp3 (0=Disabled
1=Manual 2=SingleAuto 3=AdvCal)
Service.Calibration.ChanProcMode4 3314 3314 Word R/W
cal proc mode comp4 (0=Disabled
1=Manual 2=SingleAuto 3=AdvCal)
Service.Calibration.ChanProcMode5 3315 3315 Word R/W
cal proc mode comp5 (0=Disabled
1=Manual 2=SingleAuto 3=AdvCal)
Service.Calibration.Tubing 3316 3316 Word R/W Tubing (0=Parallel 1=Serial)
Service.General.ChannelActive1 3001 3001 Word R/W built-in component1
Service.General.ChannelActive2 3002 3002 Word R/W built-in component2
Service.General.ChannelActive3 3003 3003 Word R/W built-in component3
Service.General.ChannelActive4 3004 3004 Word R/W built-in component4
Service.General.ChannelActive5 3005 3005 Word R/W built-in component5
Service.General.Identication.CPLDVersion 4028 4028 Word RO Version number of CPLD rmware
Service.General.Identication.Manufacturing-
Info
3251…
3266
3251…
3266
String RO
Infos stored for manufacturing pur-
poses
Service.General.Identication.ProgramVer-
sionDate
4017…
4022
4017…
4022
String RO software release date
Service.General.Identication.SensorBuild
4027…
0000
4027…
0000
Word RO Build number of sensor rmware
Service.General.Identication.SerialNumber
3141…
3147
3141…
3147
String R/W serial number of the device
Service.IO.InputSimEnable1 3180 3180 Word R/W
Enable Inputs Simulation of XDIO Card
#1
Service.IO.InputSimEnable2 3200 3200 Word R/W
Enable Inputs Simulation of XDIO Card
#2
Service.IO.InputSimVal1 3235 3235 Word R/W
Simulation Input state of a XDIO Card
#1
Service.IO.InputSimVal2 3250 3250
Word R/W
Simulation Input state of a XDIO Card
#2
Service.Measurement.AbsMaxRange1
6323…
6324
9162 Float R/W absolute maximum range of comp1
Service.Measurement.AbsMaxRange2
6327…
6328
9164 Float R/W absolute maximum range of comp2
Service.Measurement.AbsMaxRange3
6331…
6332
9166 Float R/W absolute maximum range of comp3
Service.Measurement.AbsMaxRange4
6335…
6336
9168 Float R/W absolute maximum range of comp4
Service.Measurement.AbsMaxRange5
6339…
6340
9170 Float R/W absolute maximum range of comp5
Service.Measurement.AbsMinRange1
6321…
6322
9161 Float R/W absolute minimum range of comp1
Service.Measurement.AbsMinRange2
6325…
6326
9163 Float R/W absolute minimum range of comp2
Service.Measurement.AbsMinRange3
6329…
6330
9165 Float R/W absolute minimum range of comp3
Service.Measurement.AbsMinRange4
6333…
6334
9167 Float R/W absolute minimum range of comp4
