Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Control.Calibration.Span_5 2010 2010 Boolean R/W Span calibration comp5 (1=start)
Control.Calibration.Span_All 2022 2022 Boolean R/W Span calibration all (1=start)
Control.Calibration.Zero_1 2001 2001 Boolean R/W Zero calibration comp1 (1=start)
Control.Calibration.Zero_2 2002 2002 Boolean R/W Zero calibration comp2 (1=start)
Control.Calibration.Zero_3 2003 2003 Boolean R/W Zero calibration comp3 (1=start)
Control.Calibration.Zero_4 2004 2004 Boolean R/W Zero calibration comp4 (1=start)
Control.Calibration.Zero_5 2005 2005 Boolean R/W Zero calibration comp5 (1=start)
Control.Calibration.Zero_All 2021 2021 Boolean R/W Zero calibration all (1=start)
Control.Calibration.ZeroSpan_1 2011 2011 Boolean R/W Zero+span calibration comp1 (1=start)
Control.Calibration.ZeroSpan_2 2012 2012 Boolean R/W Zero+span calibration comp1 (1=start)
Control.Calibration.ZeroSpan_3 2013 2013 Boolean R/W Zero+span calibration comp1 (1=start)
Control.Calibration.ZeroSpan_4 2014 2014 Boolean R/W Zero+span calibration comp1 (1=start)
Control.Calibration.ZeroSpan_5 2015 2015 Boolean R/W Zero+span calibration comp1 (1=start)
Control.Calibration.ZeroSpan_All 2023 2023 Boolean R/W Zero+span calibration all (1=start)
Control.Range.CurrentRange1 3451 3451 Word R/W
current range comp1 (0=R1, 1=R2,
2=R3, 3=R4)
Control.Range.CurrentRange2 3452 3452 Word R/W
current range comp2 (0=R1, 1=R2,
2=R3, 3=R4)
Control.Range.CurrentRange3 3453 3453 Word R/W
current range comp3 (0=R1, 1=R2,
2=R3, 3=R4)
Control.Range.CurrentRange4 3454 3454 Word R/W
current range comp4 (0=R1, 1=R2,
2=R3, 3=R4)
Control.Range.CurrentRange5 3455 3455 Word R/W
current range comp5 (0=R1, 1=R2,
2=R3, 3=R4)
Info.InterfaceID 4033 4033 Word RO
ID of used Interface(1=SerProc
2=SerSvc 17=ETH1 18=ETH2)
Info.ProgramVersion
4011…
4016
4011…
4016
String RO software release version
Info.SensorVersion 4026 4026 Word RO Version number of sensor rmware
Info.SerialNumber
3141…
3147
3141…
3147
String RO serial number of the device
PV1
6001…
6002
9001 Float RO Primary Variable 1
PV2
6003…
6004
9002 Float RO Primary Variable 2
PV3
6005…
6006
9003 Float RO Primary Variable 3
PV4
6007…
6008
9004 Float RO Primary Variable 4
PV5
6009…
6010
9005 Float RO Primary Variable 5
Service.Calibration.ChanProcMode1 3311 3311 Word R/W
cal proc mode comp1 (0=Disabled
1=Manual 2=SingleAuto 3=AdvCal)
Service.Calibration.ChanProcMode2 3312 3312 Word R/W
cal proc mode comp2 (0=Disabled
1=Manual 2=SingleAuto 3=AdvCal)
