Emerson Process Management GmbH & Co. OHG9-22
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.In/Outputs.AO.HighCutOff2
6587…
6588
9294 Float R/W higher cut off (mA) for analog output2
Setup.In/Outputs.AO.HighCutOff3
6591…
6592
9296 Float R/W higher cut off (mA) for analog output2
Setup.In/Outputs.AO.HighCutOff4
6595…
6596
9298 Float R/W higher cut off (mA) for analog output4
Setup.In/Outputs.AO.HighCutOff5
6599…
6600
9300 Float R/W higher cut off (mA) for analog output5
Setup.In/Outputs.AO.Hold1 3275 3275 Word R/W
Hold output1 on calibrations (0=Track
1=Hold)
Setup.In/Outputs.AO.Hold2 3280 3280 Word R/W
Hold output2 on calibrations (0=Track
1=Hold)
Setup.In/Outputs.AO.Hold3 3285 3285 Word R/W
Hold output3 on calibrations (0=Track
1=Hold)
Setup.In/Outputs.AO.Hold4 3290 3290 Word R/W
Hold output4 on calibrations (0=Track
1=Hold)
Setup.In/Outputs.AO.Hold5 3295 3295 Word R/W
Hold output5 on calibrations (0=Track
1=Hold)
Setup.In/Outputs.AO.LowCutOff1
6581…
6582
9291 Float R/W lower cut off (mA) for analog output1
Setup.In/Outputs.AO.LowCutOff2
6585…
6586
9293 Float R/W lower cut off (mA) for analog output2
Setup.In/Outputs.AO.LowCutOff3
6589…
6590
9295 Float R/W lower cut off (mA) for analog output3
Setup.In/Outputs.AO.LowCutOff4
6593…
6594
9297 Float R/W lower cut off (mA) for analog output4
Setup.In/Outputs.AO.LowCutOff5
6597…
6598
9299 Float R/W lower cut off (mA) for analog output5
Setup.In/Outputs.AO.NumberOuts 3270 3270 Word R/W number of analog outputs
Setup.In/Outputs.AO.OutRange1 3272 3272 Word R/W
range of output1 (0=0..20mA 1=4-
20mA)
Setup.In/Outputs.AO.OutRange2 3277 3277 Word R/W
range of output2 (0=0..20mA 1=4-
20mA)
Setup.In/Outputs.AO.OutRange3 3282 3282 Word R/W
range of output3 (0=0..20mA 1=4-
20mA)
Setup.In/Outputs.AO.OutRange4 3287 3287 Word R/W
range of output4 (0=0..20mA 1=4-
20mA)
Setup.In/Outputs.AO.OutRange5 3292 3292 Word R/W
range of output5 (0=0..20mA 1=4-
20mA)
Setup.In/Outputs.AO.SignalAsgn1 3271 3271 Word R/W assigned signal output1
Setup.In/Outputs.AO.SignalAsgn2 3276 3276 Word R/W assigned signal output2
Setup.In/Outputs.AO.SignalAsgn3 3281 3281 Word R/W assigned signal output3
Setup.In/Outputs.AO.SignalAsgn4 3286 3286 Word R/W assigned signal output4
Setup.In/Outputs.AO.SignalAsgn5 3291 3291 Word R/W assigned signal output5
Setup.In/Outputs.AO.StartRange1
6361…
6362
9181 Float R/W
level where analoge output scaling
starts on output1
