Emerson X-STREAM XE - Page 437

Emerson Process Management GmbH & Co. OHG 9-23
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.In/Outputs.AO.StartRange2
6369…
6370
9185 Float R/W
level where analoge output scaling
starts on output2
Setup.In/Outputs.AO.StartRange3
6377…
6378
9189 Float R/W
level where analoge output scaling
starts on output3
Setup.In/Outputs.AO.StartRange4
6385…
6386
9193 Float R/W
level where analoge output scaling
starts on output4
Setup.In/Outputs.AO.StartRange5
6393…
6394
9197 Float R/W
level where analoge output scaling
starts on output5
Setup.In/Outputs.DI.Node_DI1 3221 3221 Word R/W node of DigInp1 / XDIO1 Inp1
Setup.In/Outputs.DI.Node_DI10 3238 3238 Word R/W node of DigInp10 / XDIO2 Inp3
Setup.In/Outputs.DI.Node_DI11 3239 3239 Word R/W node of DigInp11 / XDIO2 Inp4
Setup.In/Outputs.DI.Node_DI12 3240 3240 Word R/W node of DigInp12 / XDIO2 Inp5
Setup.In/Outputs.DI.Node_DI13 3241 3241 Word R/W node of DigInp13 / XDIO2 Inp6
Setup.In/Outputs.DI.Node_DI14 3242 3242 Word R/W node of DigInp14 / XDIO2 Inp7
Setup.In/Outputs.DI.Node_DI2 3222 3222 Word R/W node of DigInp2 / XDIO1 Inp2
Setup.In/Outputs.DI.Node_DI3 3223 3223 Word R/W node of DigInp3 / XDIO1 Inp3
Setup.In/Outputs.DI.Node_DI4 3224 3224 Word R/W node of DigInp4 / XDIO1 Inp4
Setup.In/Outputs.DI.Node_DI5 3225 3225 Word R/W node of DigInp5 / XDIO1 Inp5
Setup.In/Outputs.DI.Node_DI6 3226 3226 Word R/W node of DigInp6 / XDIO1 Inp6
Setup.In/Outputs.DI.Node_DI7 3227 3227 Word R/W node of DigInp7 / XDIO1 Inp7
Setup.In/Outputs.DI.Node_DI8 3236 3236 Word R/W node of DigInp8 / XDIO2 Inp1
Setup.In/Outputs.DI.Node_DI9 3237 3237 Word R/W node of DigInp9 / XDIO2 Inp2
Setup.In/Outputs.DI.Signal_DI1 3228 3228 Word R/W signal of DigInp1 / XDIO1 Inp1
Setup.In/Outputs.DI.Signal_DI10 3245 3245
Word R/W signal of DigInp10 / XDIO2 Inp3
Setup.In/Outputs.DI.Signal_DI11 3246 3246 Word R/W signal of DigInp11 / XDIO2 Inp4
Setup.In/Outputs.DI.Signal_DI12 3247 3247 Word R/W signal of DigInp12 / XDIO2 Inp5
Setup.In/Outputs.DI.Signal_DI13 3248 3248 Word R/W signal of DigInp13 / XDIO2 Inp6
Setup.In/Outputs.DI.Signal_DI14 3249 3249 Word R/W signal of DigInp14 / XDIO2 Inp7
Setup.In/Outputs.DI.Signal_DI2 3229 3229 Word R/W signal of DigInp2 / XDIO1 Inp2
Setup.In/Outputs.DI.Signal_DI3 3230 3230 Word R/W signal of DigInp3 / XDIO1 Inp3
Setup.In/Outputs.DI.Signal_DI4 3231 3231 Word R/W signal of DigInp4 / XDIO1 Inp4
Setup.In/Outputs.DI.Signal_DI5 3232 3232 Word R/W signal of DigInp5 / XDIO1 Inp5
Setup.In/Outputs.DI.Signal_DI6 3233 3233 Word R/W signal of DigInp6 / XDIO1 Inp6
Setup.In/Outputs.DI.Signal_DI7 3234 3234 Word R/W signal of DigInp7 / XDIO1 Inp7
Setup.In/Outputs.DI.Signal_DI8 3243 3243 Word R/W signal of DigInp8 / XDIO2 Inp1
Setup.In/Outputs.DI.Signal_DI9 3244 3244 Word R/W signal of DigInp9 / XDIO2 Inp2
Setup.In/Outputs.DO.Node_DO1 3151 3151 Word R/W node of DigOut1 / XPSA
Setup.In/Outputs.DO.Node_DO10 3166 3166 Word R/W node of DigOut10 / XDIO1 Out6
Setup.In/Outputs.DO.Node_DO11 3167 3167 Word R/W node of DigOut11 / XDIO1 Out7
Setup.In/Outputs.DO.Node_DO12 3168 3168 Word R/W node of DigOut12 / XDIO1 Out8
Setup.In/Outputs.DO.Node_DO13 3169 3169 Word R/W node of DigOut13 / XDIO1 Out9
Setup.In/Outputs.DO.Node_DO14 3181 3181 Word R/W node of DigOut14 / XDIO2 Out1
Setup.In/Outputs.DO.Node_DO15 3182 3182 Word R/W node of DigOut15 / XDIO2 Out2
Setup.In/Outputs.DO.Node_DO16 3183 3183 Word R/W node of DigOut16 / XDIO2 Out3
