9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.In/Outputs.DO.Node_DO17 3184 3184 Word R/W node of DigOut17 / XDIO2 Out4
Setup.In/Outputs.DO.Node_DO18 3185 3185 Word R/W node of DigOut18 / XDIO2 Out5
Setup.In/Outputs.DO.Node_DO19 3186 3186 Word R/W node of DigOut19 / XDIO2 Out6
Setup.In/Outputs.DO.Node_DO2 3152 3152 Word R/W node of DigOut2 / XPSA
Setup.In/Outputs.DO.Node_DO20 3187 3187 Word R/W node of DigOut20 / XDIO2 Out7
Setup.In/Outputs.DO.Node_DO21 3188 3188 Word R/W node of DigOut21 / XDIO2 Out8
Setup.In/Outputs.DO.Node_DO22 3189 3189 Word R/W node of DigOut22 / XDIO2 Out9
Setup.In/Outputs.DO.Node_DO3 3153 3153 Word R/W node of DigOut3 / XPSA
Setup.In/Outputs.DO.Node_DO4 3154 3154 Word R/W node of DigOut4 / XPSA
Setup.In/Outputs.DO.Node_DO5 3161 3161 Word R/W node of DigOut5 / XDIO1 Out1
Setup.In/Outputs.DO.Node_DO6 3162 3162 Word R/W node of DigOut6 / XDIO1 Out2
Setup.In/Outputs.DO.Node_DO7 3163 3163 Word R/W node of DigOut7 / XDIO1 Out3
Setup.In/Outputs.DO.Node_DO8 3164 3164 Word R/W node of DigOut8 / XDIO1 Out4
Setup.In/Outputs.DO.Node_DO9 3165 3165 Word R/W node of DigOut9 / XDIO1 Out5
Setup.In/Outputs.DO.Signal_DO1 3156 3156 Word R/W signal of DigOut1 / XPSA
Setup.In/Outputs.DO.Signal_DO10 3176 3176 Word R/W signal of DigOut10 / XDIO1 Out6
Setup.In/Outputs.DO.Signal_DO11 3177 3177 Word R/W signal of DigOut11 / XDIO1 Out7
Setup.In/Outputs.DO.Signal_DO12 3178 3178 Word R/W signal of DigOut12 / XDIO1 Out8
Setup.In/Outputs.DO.Signal_DO13 3179 3179 Word R/W signal of DigOut13 / XDIO1 Out9
Setup.In/Outputs.DO.Signal_DO14 3191 3191 Word R/W signal of DigOut14 / XDIO2 Out1
Setup.In/Outputs.DO.Signal_DO15 3192 3192 Word R/W
signal of DigOut15 / XDIO2 Out2
Setup.In/Outputs.DO.Signal_DO16 3193 3193 Word R/W signal of DigOut16 / XDIO2 Out3
Setup.In/Outputs.DO.Signal_DO17 3194 3194 Word R/W signal of DigOut17 / XDIO2 Out4
Setup.In/Outputs.DO.Signal_DO18 3195 3195 Word R/W signal of DigOut18 / XDIO2 Out5
Setup.In/Outputs.DO.Signal_DO19 3196 3196 Word R/W signal of DigOut19 / XDIO2 Out6
Setup.In/Outputs.DO.Signal_DO2 3157 3157 Word R/W signal of DigOut2 / XPSA
Setup.In/Outputs.DO.Signal_DO20 3197 3197 Word R/W signal of DigOut20 / XDIO2 Out7
Setup.In/Outputs.DO.Signal_DO21 3198 3198 Word R/W signal of DigOut21 / XDIO2 Out8
Setup.In/Outputs.DO.Signal_DO22 3199 3199 Word R/W signal of DigOut22 / XDIO2 Out9
Setup.In/Outputs.DO.Signal_DO3 3158 3158 Word R/W signal of DigOut3 / XPSA
Setup.In/Outputs.DO.Signal_DO4 3159 3159 Word R/W signal of DigOut4 / XPSA
Setup.In/Outputs.DO.Signal_DO5 3171 3171 Word R/W signal of DigOut5 / XDIO1 Out1
Setup.In/Outputs.DO.Signal_DO6 3172 3172 Word R/W signal of DigOut6 / XDIO1 Out2
Setup.In/Outputs.DO.Signal_DO7 3173 3173 Word R/W signal of DigOut7 / XDIO1 Out3
Setup.In/Outputs.DO.Signal_DO8 3174 3174 Word R/W signal of DigOut8 / XDIO1 Out4
Setup.In/Outputs.DO.Signal_DO9 3175 3175 Word R/W signal of DigOut9 / XDIO1 Out5
Setup.In/Outputs.SHS.Node_Gas1 3201 3201 Word R/W node of SHS GasOut1
Setup.In/Outputs.SHS.Node_Gas2 3202 3202 Word R/W node of SHS GasOut2
Setup.In/Outputs.SHS.Node_Gas3 3203 3203 Word R/W node of SHS GasOut3
Setup.In/Outputs.SHS.Node_Gas4 3204 3204 Word R/W node of SHS GasOut4
Setup.In/Outputs.SHS.Node_Gas5 3205 3205 Word R/W node of SHS GasOut5
Setup.In/Outputs.SHS.Node_Gas6 3206 3206 Word R/W node of SHS GasOut6
