Emerson X-STREAM XE - Page 439

Emerson Process Management GmbH & Co. OHG 9-25
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.In/Outputs.SHS.Node_Gas7 3207 3207 Word R/W node of SHS GasOut7
Setup.In/Outputs.SHS.Node_Gas8 3208 3208 Word R/W node of SHS GasOut8
Setup.In/Outputs.SHS.Node_Pump1 3209 3209 Word R/W node of SHS Pump1
Setup.In/Outputs.SHS.Node_Pump2 3210 3210 Word R/W node of SHS Pump1
Setup.In/Outputs.SHS.Signal_Gas1 3211 3211 Word R/W signal of SHS GasOut1
Setup.In/Outputs.SHS.Signal_Gas2 3212 3212 Word R/W signal of SHS GasOut2
Setup.In/Outputs.SHS.Signal_Gas3 3213 3213 Word R/W signal of SHS GasOut3
Setup.In/Outputs.SHS.Signal_Gas4 3214 3214 Word R/W signal of SHS GasOut4
Setup.In/Outputs.SHS.Signal_Gas5 3215 3215 Word R/W signal of SHS GasOut5
Setup.In/Outputs.SHS.Signal_Gas6 3216 3216 Word R/W signal of SHS GasOut6
Setup.In/Outputs.SHS.Signal_Gas7 3217 3217 Word R/W signal of SHS GasOut7
Setup.In/Outputs.SHS.Signal_Gas8 3218 3218 Word R/W signal of SHS GasOut8
Setup.In/Outputs.SHS.Signal_Pump1 3219 3219 Word R/W signal of SHS Pump1
Setup.In/Outputs.SHS.Signal_Pump2 3220 3220 Word R/W signal of SHS Pump1
Setup.Measurement.EndOfCurrentRange_1
6043…
6044
9022 Float R/W end of current range of comp1
Setup.Measurement.EndOfCurrentRange_2
6047…
6048
9024 Float R/W end of current range of comp2
Setup.Measurement.EndOfCurrentRange_3
6051…
6052
9026 Float R/W end of current range of comp3
Setup.Measurement.EndOfCurrentRange_4
6055…
6056
9028 Float R/W end of current range of comp4
Setup.Measurement.EndOfCurrentRange_5
6059…
6060
9030 Float R/W end of current range of comp5
Setup.Measurement.EndOfRange1_1
6143…
6144
9072 Float R/W
end of range1 of comp1
Setup.Measurement.EndOfRange1_2
6159…
6160
9080 Float R/W end of range1 of comp2
Setup.Measurement.EndOfRange1_3
6175…
6176
9088 Float R/W end of range1 of comp3
Setup.Measurement.EndOfRange1_4
6191…
6192
9096 Float R/W end of range1 of comp4
Setup.Measurement.EndOfRange1_5
6207…
6208
9104 Float R/W end of range1 of comp5
Setup.Measurement.EndOfRange2_1
6147…
6148
9074 Float R/W end of range2 of comp1
Setup.Measurement.EndOfRange2_2
6163…
6164
9082 Float R/W end of range2 of comp2
Setup.Measurement.EndOfRange2_3
6179…
6180
9090 Float R/W end of range2 of comp3
Setup.Measurement.EndOfRange2_4
6195…
6196
9098 Float R/W end of range2 of comp4
Setup.Measurement.EndOfRange2_5
6211…
6212
9106 Float R/W end of range2 of comp5
Setup.Measurement.EndOfRange3_1
6151…
6152
9076 Float R/W end of range3 of comp1
