Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 9-63
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
9561…
9565
7121…
7130
Service.Measurement.Lin.Set1Co-
effs1
Float R/W Lin-Polynom. Set1-Coeffs (A0..4) for comp1
9566…
9570
7131…
7140
Service.Measurement.Lin.Set2Co-
effs1
Float R/W Lin-Polynom. Set2-Coeffs (A0..4) for comp1
9571…
9575
7141…
7150
Service.Measurement.Lin.Set3Co-
effs1
Float R/W Lin-Polynom. Set3-Coeffs (A0..4) for comp1
9576…
9580
7151…
7160
Service.Measurement.Lin.Set4Co-
effs1
Float R/W Lin-Polynom. Set4-Coeffs (A0..4) for comp1
9581…
9584
7161…
7168
Service.Measurement.Lin.Over-
owPerc1
Float R/W Lin-Overow [%] for Range1..4 of comp1
9585…
9588
7169…
7176
Service.Measurement.Lin.Under-
owPerc1
Float R/W Lin-Underow [%] for Range1..4 of comp1
9597…
9600
7193…
7200
Service.Measurement.Lin.RefVal-
PolySets1
Float R/W Reference value for PolynSets (P1..P4) of comp1
9601…
9603
7201…
7206
Service.Measurement.Lin.TableX-
Values2
Float R/W Linearization table X-Values of comp2
9631…
9633
7261…
7266
Service.Measurement.Lin.Tab-
leYValues2
Float R/W Linearization table Y-Values of comp2
9661…
9665
7321…
7330
Service.Measurement.Lin.Set1Co-
effs2
Float R/W Lin-Polynom. Set1-Coeffs (A0..4) for comp2
9666…
9670
7331…
7340
Service.Measurement.Lin.Set2Co-
effs2
Float R/W Lin-Polynom. Set2-Coeffs (A0..4) for comp2
9671…
9675
7341…
7350
Service.Measurement.Lin.Set3Co-
effs2
Float R/W Lin-Polynom. Set3-Coeffs (A0..4) for comp2
9676…
9680
7351…
7360
Service.Measurement.Lin.Set4Co
-
effs2
Float R/W Lin-Polynom. Set4-Coeffs (A0..4) for comp2
9681…
9684
7361…
7368
Service.Measurement.Lin.Over-
owPerc2
Float R/W Lin-Overow [%] for Range1..4 of comp2
9685…
9688
7369…
7376
Service.Measurement.Lin.Under-
owPerc2
Float R/W Lin-Underow [%] for Range1..4 of comp2
9697…
9700
7393…
7400
Service.Measurement.Lin.RefVal-
PolySets2
Float R/W Reference value for PolynSets (P1..P4) of comp2
9701…
9703
7401…
7406
Service.Measurement.Lin.TableX-
Values3
Float R/W Linearization table X-Values of comp3
9731…
9733
7461…
7466
Service.Measurement.Lin.Tab-
leYValues3
Float R/W Linearization table Y-Values of comp3
9761…
9765
7521…
7530
Service.Measurement.Lin.Set1Co-
effs3
Float R/W Lin-Polynom. Set1-Coeffs (A0..4) for comp3
9766…
9770
7531…
7540
Service.Measurement.Lin.Set2Co-
effs3
Float R/W Lin-Polynom. Set2-Coeffs (A0..4) for comp3
9771…
9775
7541…
7550
Service.Measurement.Lin.Set3Co-
effs3
Float R/W Lin-Polynom. Set3-Coeffs (A0..4) for comp3
