Emotron AFR 2.0 Series User Manual

102 Functional description CG Drives & Automation 01-7318-01r1
Analogue Comparator 2, Level Low [6123]
Function is identical to analogue comparator 1,
level low [6113].
Analogue Comparator 2, Type [6124]
Function is identical to analogue comparator 1,
Type [6114].
Analogue Comparator 2, Polar [6125]
Function is identical to analogue comparator 1,
Polar [6115].
CA3 Setup [613]
Analogue comparators 3, parameter group.
Analogue Comparator 3, Value [6131]
Function is identical to analogue comparator 1,
value [6111].
Analogue Comparator 3, Level High [6132]
Function is identical to analogue comparator 1,
level high [6112].
Analogue Comparator 3, Level Low [6133]
Function is identical to analogue comparator 1,
level low [6113].
Analogue Comparator, 3 Type [6134]
Function is identical to analogue comparator 1, level Type
[6114].
Analogue Comparator 3, Polar [6135]
Function is identical to analogue comparator 1,
Polar [6115].
Default: 10%
Range: Enter a value for the low level.
Default: Hysteresis
Hysteresis 0 Hysteresis type comparator
Window 1 Window type comparator
Default: Unipolar
Unipolar 0 Absolute value of [6111] used
Bipolar 1 Signed value of [6111] used
Default: Process Val
Selections: Same as in menu [6111]
6123 CA2 Level LO
Stp 10%
6124 CA2 Type
Stp Hysteresis
6125 CA2 Polar
Stp Unipolar
6131 CA3 Value
Stp Process Val
Default: 300rpm
Range: Enter a value for the high level.
Default: 200 rpm
Range: Enter a value for the low level.
Default: Hysteresis
Hysteresis 0 Hysteresis type comparator
Window 1 Window type comparator
Default: Unipolar
Unipolar 0 Absolute value of [6111] used
Bipolar 1 Signed value of [6111] used
6132 CA3 Level HI
Stp 300rpm
6133 CA3 Level LO
Stp 200rpm
6134 CA3 Type
Stp Hysteresis
6135 CA3 Polar
Stp Unipolar
