CG Drives & Automation 01-7318-01r1 179
610 Comparators 97
611 CA1 Setup 97
6111 CA1 Value Current 43401 170/50 4D49 19785 UInt UInt 97
6112 CA1 LevelHI 30.0A 43402 170/51 4D4A 19786 Long, 1=1 or 1=0.001 EInt 99
6113 CA1 LevelLO 20.0A 43403 170/52 4D4B 19787 Long, 1=1 or 1=0.001 EInt 101
6114 CA1 Type Hysteresis 43481 170/130 4D99 19865 UInt UInt 101
6115 CA1 Polar Unipolar 43486 170/135 4D9E 19870 UInt UInt 101
612 CA2 Setup 101
6121 CA2 Value Torque 43404 170/53 4D4C 19788 UInt UInt 101
6122 CA2 LevelHI 20% 43405 170/54 4D4D 19789 Long, 1=1 or 1=0.001 EInt 101
6123 CA2 LevelLO 10% 43406 170/55 4D4E 19790 Long, 1=1 or 1=0.001 EInt 102
6124 CA2 Type Hysteresis 43482 170/131 4D9A 19866 UInt UInt 102
6125 CA2 Polar Unipolar 43487 170/136 4D9F 19871 UInt UInt 102
613 CA3 Setup 102
6131 CA3 Value Process Val 43471 170/120 4D8F 19855 UInt UInt 102
6132 CA3 LevelHI 300rpm 43472 170/121 4D90 19856 Long, 1=1 or 1=0.001 EInt 102
6133 CA3 LevelLO 200rpm 43473 170/122 4D91 19857 Long, 1=1 or 1=0.001 EInt 102
6134 CA3 Type Hysteresis 43483 170/132 4D9B 19867 UInt UInt 102
6135 CA3 Polar Unipolar 43488 170/137 4DA0 19872 UInt UInt 102
614 CA4 Setup 103
6141 CA4 Value Process Err 43474 170/123 4D92 19858 UInt UInt 103
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page
Remarks
