178 CG Drives & Automation 01-7318-01r1
55DA B3R1 Mode N.O 43527 170/176 4DC7 19911 UInt UInt 96
55DB B3R2 Mode N.O 43528 170/177 4DC8 19912 UInt UInt 96
55DC B3R3 Mode N.O 43529 170/178 4DC9 19913 UInt UInt 96
560 Virtual I/Os 96
561 VIO 1 Dest Off 43281 169/185 4CD1 19665 UInt UInt 96
562 VIO 1 Source Off 43282 169/186 4CD2 19666 UInt UInt 96
563 VIO 2 Dest Off 43283 169/187 4CD3 19667 UInt UInt 96
564 VIO 2 Source Off 43284 169/188 4CD4 19668 UInt UInt 96
565 VIO 3 Dest Off 43285 169/189 4CD5 19669 UInt UInt 96
566 VIO 3 Source Off 43286 169/190 4CD6 19670 UInt UInt 96
567 VIO 4 Dest Off 43287 169/191 4CD7 19671 UInt UInt 96
568 VIO 4 Source Off 43288 169/192 4CD8 19672 UInt UInt 96
569 VIO 5 Dest Off 43289 169/193 4CD9 19673 UInt UInt 96
56A VIO 5 Source Off 43290 169/194 4CDA 19674 UInt UInt 96
56B VIO 6 Dest Run R 43291 169/195 4CDB 19675 UInt UInt 96
56C VIO 6 Source DigIn 1 43292 169/196 4CDC 19676 UInt UInt 96
56D VIO 7 Dest Run L 43293 169/197 4CDD 19677 UInt UInt 96
56E VIO 7 Source DigIn 2 43294 169/198 4CDE 19678 UInt UInt 96
56F VIO 8 Dest Off 43295 169/199 4CDF 19679 UInt UInt 96
56G VIO 8 Source Operation 43296 169/200 4CE0 19680 UInt UInt 96
600 Logic&Timers 97
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page
Remarks
