78 Functional description CG Drives & Automation 01-7318-01r1
Over current F [
25O
]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Over Speed [
25Q
]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
External Motor Temperature [
25R
]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
Liquid cooling low level [
25T
]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
11.4.4 Serial Communication [
260
]
This function is to define the communication parameters for
serial communication. There are two types of options
available for serial communication, RS232/485 (Modbus/
RTU) and fieldbus modules (CANopen, Profibus,
DeviceNet, Modbus/TCP, Profinet IO, EtherCAT and
EtherNet/IP).
For more information see section 10. and respective option
manual.
Comm Type [
261
]
Select RS232/485 [262] or Fieldbus [263].
RS232/485 [
262
]
Press Enter to set up the parameters for RS232/485
(Modbus/RTU) communication.
Baud rate [2621]
Set the baud rate for the communication.
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Default: RS232/485
RS232/485 0 RS232/485 selected
Fieldbus 1
Fieldbus selected (CANopen, Profibus,
DeviceNet, Modbus/TCP, Profinet IO,
EtherCAT or EtherNet/IP)
NOTE: Toggling the setting in this menu will perform a
soft reset (re-boot) of the Fieldbus module.
NOTE:
This baud rate is only used for the isolated RS232/
485 option.
Default: 9600
2400 0
Selected baud rate
4800 1
9600 2
19200 3
38400 4
261 Com Type
Stp RS232/485
