114 Functional Description Emotron AB 01-3694-01r2
AnIn1 Advanced [513]
AnIn1 Min [5131]
Parameter to set the minimum value of the external refer-
ence signal. Only visible if [512] = User mA/V.
Communication information
AnIn1 Max [5132]
Parameter to set the maximum value of the external refer-
ence signal. Only visible if [512] = User mA/V.
Communication information
Special function: Inverted reference signal
If the AnIn minimum value is higher than the AnIn maxi-
mum value, the input will act as an inverted reference input,
see Fig. 101.
Fig. 101 Inverted reference
AnIn1 Bipol [5133]
This menu is automatically displayed if AnIn1 Setup is set to
User Bipol mA or User Bipol V. The window will automati-
cally show mA or V range according to selected function.
The range is set by changing the positive maximum value;
the negative value is automatically adapted accordingly.
Only visible if [512] = User Bipol mA/V. The inputs RunR
and RunL input need to be active, and Rotation, [219],
must be set to “R+L”, to operate the bipolar function on the
analogue input.
Communication information
AnIn1 Function Min [5134]
With AnIn1 Function Min the physical minimum value is
scaled to selected process unit. The default scaling is
dependent of the selected function of AnIn1 [511].
NOTE: The different menus will automatically be set to
either “mA” or “V”, based on the selection in AnIn 1
Setup [512].
Default: 0 V/4.00 mA
Range:
0.00–20.00 mA
0–10.00 V
Modbus Instance no/DeviceNet no: 43203
Profibus slot/index 169/107
Fieldbus format Long
Modbus format EInt
Default: 10.00 V/20.00 mA
Range:
0.00–20.00 mA
0–10.00 V
Modbus Instance no/DeviceNet no: 43204
Profibus slot/index 169/108
Fieldbus format Long
Modbus format EInt
513 AnIn1 Advan
Stp
A
5131 AnIn1 Min
Stp 0V/4.00mA
A
5132 AnIn1 Max
Stp 10.0V/20.00mA
Default: 0.00–10.00 V
Range: 0.0–20.0 mA, 0.00–10.00 V
Modbus Instance no/DeviceNet no: 43205
Profibus slot/index 169/109
Fieldbus format Long
Modbus format EInt
Default: Min
Min 0 Min value
Max 1 Max value
User-
defined
2 Define user value in menu [5135]
010V
100 %
n
(NG_06-F25)
Invert
Ref
AnIn Min >
AnIn Max
5133 AnIn1 Bipol
Stp 10.00V
A
5134 AnIn1 FcMin
Stp Min
A
