Emotron AB 01-3694-01r2 Functional Description 115
Table 24 shows corresponding values for the min and max
selections depending on the function of the analogue input
[511].
Communication information
AnIn1 Function Value Min [5135]
With AnIn1 Function ValMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5134].
Communication information
AnIn1 Function Max [5136]
With AnIn1 Function Max the physical maximum value is
scaled to selected process unit. The default scaling is
dependent of the selected function of AnIn1 [511]. See
Table 24.
Communication information
AnIn1 Function Value Max [5137]
With AnIn1 Function VaMax you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5136].
Communication information
Example:
Process sensor is a sensor with the following specification:
Range: 0–3 bar
Output: 2–10 mA
Analogue input should be set up according to:
[512] AnIn1 Setup = User mA
[5131] AnIn1 Min = 2 mA
[5132] AnIn1 Max = 10 mA
[5134] AnIn1 Function Min = User-defined
[5135] AnIn1 VaMin = 0.000 bar
[5136] AnIn 1 Function Max = User-defined
[5137] AnIn1 VaMax = 3.000 bar
Ta b le 2 4
AnIn Function Min Max
Speed Min Speed [341] Max Speed [343]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
Process Value Process Min [324] Process Max [325]
Modbus Instance no/DeviceNet no: 43206
Profibus slot/index 169/110
Fieldbus format UInt
Modbus format UInt
Default: 0.000
Range: -10000.000 – 10000.000
Modbus Instance no/DeviceNet no: 43541
Profibus slot/index 170/190
Fieldbus format
Long,
Speed 1=1 rpm
Torque 1=1%
Process val 1=0.001
Modbus format EInt
Default: Max
Min 0 Min value
Max 1 Max value
User-def. 2 Define user value in menu [5137]
5135 AnIn1 VaMin
Stp 0.000
A
5136 AnIn1 FcMax
Stp Max
A
Modbus Instance no/
DeviceNet no:
43207
Profibus slot/index 169/111
Fieldbus format
Long,
Speed/Torque 1=1 rpm or %.
Other 1= 0.001
Modbus format EInt
Default: 0.000
Range: -10000.000 – 10000.000
Modbus Instance no/DeviceNet no: 43551
Profibus slot/index 170/200
Fieldbus format
Long,
Speed 1=1 rpm
Torque 1=1%
Process val 1=0.001
Modbus format EInt
NOTE: With AnIn Min, AnIn Max, AnIn Function Min and
AnIn Function Max settings, loss of feedback signals
(e.g. voltage drop due to long sensor wiring) can be
compensated to ensure an accurate process control.
5137 AnIn1 VaMax
Stp 0.000
A
