Emotron FDU48-210 User Manual

Emotron AB 01-3694-01r2 Functional Description 117
AnIn2 Advanced [516]
Same functions and submenus as under AnIn1 Advanced
[513].
Communication information
AnIn3 Function [517]
Parameter for setting the function of Analogue Input 3.
Same function as AnIn1 Func [511].
Communication information
AnIn3 Setup [518]
Same functions as AnIn1 Setup [512].
Communication information
AnIn3 Advanced [519]
Same functions and submenus as under AnIn1 Advanced
[513].
Communication information
AnIn4 Function [51A]
Parameter for setting the function of Analogue Input 4.
Same function as AnIn1 Func [511].
Communication information
AnIn4 Set-up [51B]
Same functions as AnIn1 Setup [512].
Communication information
Modbus Instance no/DeviceNet no:
43213–43219
43542
43552
Profibus slot/index
169/117–123
170/191
170/201
Default: Off
Selection: Same as in menu
[511]
Modbus Instance no/DeviceNet no: 43221
Profibus slot/index 169/125
Fieldbus format UInt
Modbus format UInt
Default: 4–20 mA
Dependent on Setting of switch S3
Selection: Same as in menu
[512].
Modbus Instance no/DeviceNet no: 43222
Profibus slot/index 169/126
Fieldbus format UInt
Modbus format UInt
516 AnIn2 Advan
Stp
A
517 AnIn3 Fc
Stp Off
A
518 AnIn3 Setup
Stp 4-20mA
A
Modbus Instance no/DeviceNet no:
43223–43229
43543
43553
Profibus slot/index
169/127–169/133
170/192
170/202
Default: Off
Selection: Same as in menu
[511]
Modbus Instance no/DeviceNet no: 43231
Profibus slot/index 169/135
Fieldbus format UInt
Modbus format UInt
Default: 4-20 mA
Dependent on Setting of switch S4
Selection: Same as in menu [512].
Modbus Instance no/DeviceNet no: 43232
Profibus slot/index 169/136
Fieldbus format UInt
Modbus format UInt
519 AnIn3 Advan
Stp
A
51A AnIn4 Fc
Stp Off
A
51B AnIn4 Setup
Stp 4-20mA
A
