Process Unit [322]
Communication information
User-defined Unit [323]
This menu is only displayed if User is selected in menu
[322]. The function enables the user to define a unit with six
symbols. Use the Prev and Next key to move the cursor to
required position. Then use the + and - keys to scroll down
the character list. Confirm the character by moving the cur-
sor to the next position by pressing the Next key.
Default: Speed
F(AnIn) 0 Function of analogue input
Speed 1
Torque 2
PT100 3
F(Speed) 4 Function of speed
F(Torque) 5 Function of torque
F(Bus) 6 Function of communication
NOTE: When PT100 is selected, use PT100 channel 1 on
the PTC/PT100 option board.
Modbus Instance no/DeviceNet no: 43302
Profibus slot/index 169/206
Fieldbus format UInt
Modbus format UInt
Default: rpm
Off 0 No unit selection
%1Percent
°C 2 Degrees Centigrade
°F 3 Degrees Fahrenheit
bar 4 bar
Pa 5 Pascal
Nm 6 Torque
Hz 7 Frequency
rpm 8 Revolutions per minute
m
3
/h 9 Cubic meters per hour
gal/h 10 Gallons per hour
ft
3
/h 11 Cubic feet per hour
User 12 User defined unit
321 Proc Source
Stp Speed
A
322 Proc Unit
Stp rpm
A
Modbus Instance no/DeviceNet no: 43303
Profibus slot/index 169/207
Fieldbus format UInt
Modbus format UInt
Character
No. for serial
comm.
Character
No. for serial
comm.
Space 0 m 58
0–9 1–10 n 59
A11ñ60
B12o61
C13ó62
D14 ô 63
E15p64
F16q65
G17 r 66
H18 s 67
I19t68
J20u69
K21 ü70
L22v71
M23 w72
N24 x 73
O25 y 74
P26z75
Q27 å76
R28ä77
S29ö78
T30! 79
U31 ¨80
Ü32#81
V33$82
W34 %83
X35&84
Y36· 85
