AnOut1 Function Value Max [5337]
With AnOut1 Function VaMax you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
Communication information
AnOut2 Function [534]
Sets the function for the Analogue Output 2.
Communication information
AnOut2 Setup [535]
Preset scaling and offset of the output configuration for ana-
logue output 2.
Communication information
AnOut2 Advanced [536]
Same functions and submenus as under AnOut1 Advanced
[533].
Communication information
Modbus Instance no/DeviceNet no: 43257
Profibus slot/index 169/161
Fieldbus format Long, 0.001
Modbus format EInt
NOTE: It is possible to set AnOut1 up as an inverted
output signal by setting AnOut1 Min > AnOut1 Max. See
Fig. 92.
Default: 0.000
Range: -10000.000–10000.000
Modbus Instance no/DeviceNet no: 43555
Profibus slot/index 170/204
Fieldbus format
Long,
Speed 1=1 rpm
Torque 1=1%
Process val 1=0.001
Modbus format EInt
Default: Torque
Selection: Same as in menu
[531]
Modbus Instance no/DeviceNet no: 43261
Profibus slot/index 169/165
Fieldbus format UInt
Modbus format UInt
5337 AnOut1VaMax
Stp 0.000
A
534 AnOut2 Fc
Stp Torque
A
Default: 4-20mA
Selection: Same as in menu
[532]
Modbus Instance no/DeviceNet no: 43262
Profibus slot/index 169/166
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no:
43263–43267
43546
43556
Profibus slot/index
169/167–169/171
170/195
170/205
535 AnOut2 Setup
Stp 4-20mA
A
536 AnOut2 Advan
Stp
A
