Special function: Inverted reference signal
If the AnIn minimum value is higher than the AnIn maxi-
mum value, the input will act as an inverted reference input,
see Fig. 92.
Fig. 92 Inverted reference
AnIn1 Bipol [5133]
This menu is automatically displayed if AnIn1 Setup is set to
User Bipol mA or User Bipol V. The window will automati-
cally show mA or V range according to selected function.
The range is set by changing the positive maximum value;
the negative value is automatically adapted accordingly.
Only visible if [512] = User Bipol mA/V. The inputs RunR
and RunL input need to be active, and Rotation, [219],
must be set to “R+L”, to operate the bipolar function on the
analogue input.
Communication information
AnIn1 Function Min [5134]
With AnIn1 Function Min the physical minimum value is
scaled to selected process unit. The default scaling is
dependent of the selected function of AnIn1 [511].
Table 25 shows corresponding values for the min and max
selections depending on the function of the analogue input
[511].
Communication information
AnIn1 Function Value Min [5135]
With AnIn1 Function ValMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5134].
Communication information
Default: 0.00–10.00 V
Range: 0.0–20.0 mA, 0.00–10.00 V
Modbus Instance no/DeviceNet no: 43205
Profibus slot/index 169/109
Fieldbus format Long
Modbus format EInt
010V
100 %
n
(NG_06-F25)
Invert
Ref
AnIn Min >
AnIn Max
5133 AnIn1 Bipol
Stp 10.00V
A
Default: Min
Min 0 Min value
Max 1 Max value
User-
defined
2 Define user value in menu [5135]
Ta b l e 2 5
AnIn Function Min Max
Speed Min Speed [341] Max Speed [343]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
Process Value Process Min [324] Process Max [325]
Modbus Instance no/DeviceNet no: 43206
Profibus slot/index 169/110
Fieldbus format UInt
Modbus format UInt
Default: 0.000
Range: -10000.000 – 10000.000
Modbus Instance no/DeviceNet no: 43541
Profibus slot/index 170/190
Fieldbus format
Long,
Speed 1=1 rpm
Torque 1=1%
Process val 1=0.001
Modbus format EInt
5134 AnIn1 FcMin
Stp Min
A
5135 AnIn1 VaMin
Stp 0.000
A
