122 Functional Description Emotron AB 01-4429-01r2
AnOut1 Bipol [5333]
Automatically displayed if User Bipol mA or User Bipol V is
selected in menu AnOut1 Setup. The menu will automati-
cally show mA or V range according to the selected function.
The range is set by changing the positive maximum value;
the negative value is automatically adapted accordingly.
Only visible if [512] = User Bipol mA/V.
Communication information
AnOut1 Function Min [5334]
With AnOut1 Function Min the physical minimum value is
scaled to selected presentation. The default scaling is
dependent of the selected function of AnOut1 [531].
Table 27 shows corresponding values for the min and max
selections depending on the function of the analogue output
[531].
Communication information
AnIn1 Function Value Min [5335]
With AnOut1 Function VaMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
Communication information
AnOut1 Function Max [5336]
With AnOut1 Function Min the physical minimum value is
scaled to selected presentation. The default scaling is
dependent on the selected function of AnOut1 [531]. See
Table 27.
Default: -10.00–10.00 V
Range: -10.00–10.00 V, -20.0–20.0 mA
Modbus Instance no/DeviceNet no: 43255
Profibus slot/index 169/159
Fieldbus format Long, 1=0.01
Modbus format EInt
Default: Min
Min 0 Min value
Max 1 Max value
User-defined 2 Define user value in menu [5335]
Ta b l e 2 7
AnOut
Function
Min Value Max Value
Process Value Process Min [324] Process Max [325]
Speed Min Speed [341] Max Speed [343]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
Shaft Power 0% Motor Power [223]
Frequency 0 Hz Motor Frequency [222]
Current 0 A Motor Current [224]
El Power 0 W Motor Power [223]
Output Voltage 0 V Motor Voltage [221]
5333 AnOut1Bipol
Stp -10.00-10.00V
DC voltage 0 V 1000 V
AnIn1 AnIn1 Function Min AnIn1 Function Max
AnIn2 AnIn2 Function Min AnIn2 Function Max
AnIn3 AnIn3 Function Min AnIn3 Function Max
AnIn4 AnIn4 Function Min AnIn4 Function Max
Modbus Instance no/DeviceNet no: 43256
Profibus slot/index 169/160
Fieldbus format
Long,
1=0.1 W, 0.1 Hz, 0.1 A,
0.1 V or 0.001
Modbus format EInt
Default: 0.000
Range: -10000.000–10000.000
Modbus Instance no/DeviceNet no: 43545
Profibus slot/index 170/194
Fieldbus format
Long,
Speed 1=1 rpm
Torque 1=1%
Process val 1=0.001
Modbus format EInt
Default: Max
Min 0 Min value
Max 1 Max value
User defined 2 Define user value in menu [5337]
Ta b l e 2 7
AnOut
Function
Min Value Max Value
5335 AnOut1VaMin
Stp 0.000
