SS2100i-1 Gas Analyzer
3–6 4900002224 rev. E 12-18-20
Figure 3–2 Preferred basic differential system with
one solenoid valve driving two pneumatic valves
CELL
SCRUBBER
SCRUBBER
EFFICIENCY
INDICATOR
SAMPLE
SUPPLY
SAMPLE
RETURN
INSTRUMENT
AIR SUPPLY
