SS2100i-1 Gas Analyzer
B–20 4900002224 rev. E 12-18-20
.
5. Disassemble the tubing using a 9/16” wrench. Refer to Figure B–14
below.
Figure B–13 Unpacking enclosure
insulation
Figure B–14 Flame arrestor positions inside
enclosure
TOP FLAME
ARRESTOR
BOTTOM FLAME
ARRESTOR
