6.4 Signals
LED On Flashing
POWER
24 V power supply /
SA
Indicates that at least one of the safety con-
tacts is open.
Safety test failure (terminal 41).
Operations count performed (only when control
panel is switched on):
= 1000 operations
= 10000 operations
IN
Activated at every command and adjustment
to the dip-switch and jumper.
/
11
Indicates that the 0-11 limit switch contact
is open.
/
12
Indicates that the 0-12 limit switch contact
is open.
/
SIG
Activated during the radio reception phase or
transmitter memorisation.
Indicates the absence of the memory module.
