Epson 9600 User Manual

5-136
136 | Maintaining and Transporting the Printer
Examining the UNI-D ALL Alignment Pattern
Follow these steps when the UNI-D ALL patterns finish printing:
1. Depending on the width of the paper loaded in the printer, more than
one set of patterns may be printed. Locate the patterns in the middle of
your printout. In the steps that follow, refer to those patterns to make
your adjustments, instead of the ones printed toward the left or right.
2. Look at the display screen on the printer. Notice that it is prompting
you to choose the best line in the group labeled
K2 in row #1.
Refer to middle set of
patterns when making
adjustments
Look at this group
Row #1

Epson 9600 Specifications

General

Maximum Resolution	2880 x 1440 dpi
Max Resolution (BW)	2880 x 1440 dpi
Max Resolution (Color)	2880 x 1440 dpi
Media Thickness	Up to 1.5 mm
Ink Type	UltraChrome Ink
Maximum Print Width	44 inches
Media Handling	Roll and Sheet
Ink Cartridge Type	Individual Cartridges
Connectivity	USB, Ethernet
Media Size	Up to 44 inches wide
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black
Media Width	Up to 44 inches
Interface	USB 2.0, Ethernet
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
