Epson 9600 User Manual

2-85
Handling Paper and Other Media | 85
4. Use the u and d buttons to make any necessary changes, then press
Enter to save your new setting.
5. To adjust another setting, press the
l button to return to the menu
options.
6. When done, press
Pause to exit the menu.
Creating and Selecting Paper Profiles
To create a profile for a specific paper type, make sure the paper you want to
profile is loaded in the printer. Then follow these steps:
1. Press the
SelecType button, then press the d button until PAPER
CONFIG
appears on the display.
2. Press the
r button until PAPER NUMBER appears.
3. Press the
r button.
4. Use the
u and d buttons to assign a paper profile number (1 to 10),
then press
Enter.
5. Press
Enter again to print the paper thickness pattern.
The printer prints a pattern similar to the following:
DRYING TIME Use when printing with non-EPSON media. You
can make the print head wait up to 5 seconds after
each pass to allow ink to dry on the page.
SUCTION Lets you decrease the paper suction level when
printing on thinner papers (less than 12 lb), such
as CAD drafting paper or backlight film.
PRINT ADJ Adjusts the intensity of the MicroWeave
®
pattern.
Improves print quality but lowers printing speed.
Menu option Function
Note
Any settings made this
way override settings
made in the driver or RIP
software .
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

Epson 9600 Specifications

General

Maximum Resolution	2880 x 1440 dpi
Max Resolution (BW)	2880 x 1440 dpi
Max Resolution (Color)	2880 x 1440 dpi
Media Thickness	Up to 1.5 mm
Ink Type	UltraChrome Ink
Maximum Print Width	44 inches
Media Handling	Roll and Sheet
Ink Cartridge Type	Individual Cartridges
Connectivity	USB, Ethernet
Media Size	Up to 44 inches wide
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black
Media Width	Up to 44 inches
Interface	USB 2.0, Ethernet
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
