2-75
Handling Paper and Other Media | 75
Switching Between 2-Inch and 3-Inch Roll Paper
You can convert the spindle to accept roll paper with either a 2-inch or
3-inch core. When the gray adapters are attached at each end, you can use
3-inch rolls. Follow these steps to remove the gray adapters for using 2-inch
roll paper:
1. Remove the black paper stop from the end of the spindle.
2. Press toward the center on the four tabs shown below to release the gray
adapter from the paper stop.
3. Remove the gray adapter from the white paper stop at the other end of
the spindle.
If you need to reattach the gray adapters to use 3-inch roll paper, align the
arrow marks shown below and press the adapters on until they lock in place.
press tabs to release
Note
Your adapter may have
only two tabs.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson 9600 and is the answer not in the manual?

Epson 9600 Specifications

General IconGeneral
Maximum Resolution2880 x 1440 dpi
Max Resolution (BW)2880 x 1440 dpi
Max Resolution (Color)2880 x 1440 dpi
Media ThicknessUp to 1.5 mm
Ink TypeUltraChrome Ink
Maximum Print Width44 inches
Media HandlingRoll and Sheet
Ink Cartridge TypeIndividual Cartridges
ConnectivityUSB, Ethernet
Media SizeUp to 44 inches wide
Ink ColorsCyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black
Media WidthUp to 44 inches
InterfaceUSB 2.0, Ethernet
Operating SystemsWindows, Mac OS
Print TechnologyInkjet
