Setting Up the Printer | 27
Unpacking and Assembling the Stylus Pro 9600
Follow these steps to assemble your printer. If you have a Stylus Pro 7600,
see page 18 instead.
Unpacking the Stand
1. Open the box and remove the handles from the sides of the box.
2. Lift the box up and away from the printer, then set it aside.
3. Make sure you have all these items:
Parts:
A: Left base section D: Basket hooks, long (2)
B: Right base section E: Basket hooks, short (2)
C: Support bar F: Paper basket
Warning
Two people are required to
unpack the printer, and four
are needed to set it on the
stand.
A
B
D
F
C
E
