18 | Setting Up the Printer
Unpacking and Assembling the Stylus Pro 7600
Follow these steps to assemble your printer. If you have a Stylus Pro 9600,
see page 27 instead.
Unpacking and Assembling the Optional Stand
If you have an optional stand for the Stylus Pro 7600, follow these steps to
unpack and assemble it. Otherwise, skip ahead to “Unpacking the Printer”
on page 21.
1. Unpack the stand and make sure you have all these items. You will also
need a Phillips screwdriver.
Parts:
A: Base, right and left (1 each)
B: Leg, right and left (1 each)
C: Bottom support bar(1)
D: Top support bar(1)
E: Basket hooks (4)
F: Basket (1)
Warning
Assembly requires two
people.
A
B
C
D
E
F
