Epson 9600 User Manual

1-22
22 | Setting Up the Printer
5. Take out the foam supports from under the printer.
6. Remove any packing tape. Check these areas:
• the front cover
• the ink compartment cover (in front on the left)
• the maintenance tank (on the right side near the bottom)
7. Open the front cover. Then unscrew the bolt and remove the bracket
securing the print head. Save the bolt and bracket in case you need to
ship the printer.
8. If you want to set the
printer on a desk, use at
least two people to hold
it as shown. Otherwise
follow the instructions in
the next section to mount
it on the optional stand.
Warning
Two or more people are
required to lift the printer.

Epson 9600 Specifications

General

Maximum Resolution	2880 x 1440 dpi
Max Resolution (BW)	2880 x 1440 dpi
Max Resolution (Color)	2880 x 1440 dpi
Media Thickness	Up to 1.5 mm
Ink Type	UltraChrome Ink
Maximum Print Width	44 inches
Media Handling	Roll and Sheet
Ink Cartridge Type	Individual Cartridges
Connectivity	USB, Ethernet
Media Size	Up to 44 inches wide
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black
Media Width	Up to 44 inches
Interface	USB 2.0, Ethernet
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
