Epson G20 Series User Manual

Setup & Operation 3. Environments and Installation
58 G10 / G20 Rev.20
Table Top Mounting
Fitting (black or blue)*
for ø4 mm pneumatic tube
Fitting (white)
for ø4 mm pneumatic tube
Fitting (black or blue)*
for
ø6 mm pneumatic tube
Fitting (white) for
ø6 mm pneumatic tube
User connector
(15-pin D-sub connector)
User connector
(9-pin D-sub connector)
Wall Mounting
Fitting (black or blue)*
for ø6 mm
pneumatic tube
User connector
(15-pin D-sub connector)
User connector
(9-pin D-sub connector)
Fitting (white)
for ø6 mm pneumatic tube
Fitting (black or blue)*
for ø4 mm pneumatic tube
Fitting (
white)
for ø4 mm pneumatic tube
Ceiling Mounting
Fitting (black or blue)*
for ø4 mm pneumatic tube
Fitting (white)
for ø4 mm pneumatic tube
Fitting (black or blue)*
for ø6 mm
pneumatic tube
Fitting (white)
for ø6 mm
pneumatic tube
User connector
(15-pin D-sub connector)
User connector
(9-pin D-sub connector)
