•Module: Sets the thin element width in dots.
- : Not supported
*1: In some cases, dot missing and irregularity in ink shots may occur when printing ladder
barcodes (when the barcodes from the start to stop are printed in a vertical direction),
lowering the ANSI grade to F and making barcodes unrecognizable. Therefore, fe
nce
barcodes (when the barcodes from the start to stop are printed in a horizontal direction)
are recommended to use. To use ladder barcodes, make consideration such as printing
HRI characters.
*
2: Ink may penetrate the paper due to its characteristics, and bars of printed barcodes tend to
become thicker. This tendency is more prominent with some papers. To maintain the
barcode recognition rate, use methods such as reducing the data in a bar by 1 pixel and
increasing the blank space by 1 pixel (Bar width adj
ustment). However, do not apply this
method to 2-dimensional symbols.
Category
Graphic resolu-
tions
(Horizontal x
vertical) (dpi)
Print
direction
*1
Adjust
Bar
Width *2
Upper Line: Minimum Mod-
ule [by 360 dpi]
Lower Line: Minimum Ele-
ment Ratio
ANSI
Grade
D or
higher
ANSI
Grade
C or
higher
ANSI
Grade
B or
higher
Plain,
Plain label
360 x 360
Fence
Required
4 dot
2.5
--
Ladder
6 dot
2.5
--
Synthetic label
Matte
Matte label
Glossy label
Wristband
360 x 360
Fence
3 dot
2.5
4 dot
2.5
Ladder
6 dot
2.5 (*3)
- (*3) -
720 x 360
Fence
3 dot
2.5
4 dot
2.5
Ladder
6 dot
2.5 (*3)
- (*3) -
