Epson TM-H6000 Service Manual

Rev. A Product Overview Appendix D-47
TM-H6000/H6000P Service Manual
Confidential
PE1 16 EP_TP EP_TP IN E/P timing
pulse
interrupt
PE2 17 SW_SLIP_PF SW_SLIP IN None Depressed
PE4 18 SW_RECEIPT_PF SW_RPT IN None Depressed
PE5 19 Receive DMA request receipt DREQ IN
PE6 20 Interrupt for synchronous serial
input
SD_INT IN
PF0/TXD0 21 Serial TXD for asynchronous
communication
TXD OUT
PF1/RXD0 22 Serial RXD for asynchronous
communication
RXD IN
PF2/CTS0/
SCLK0
23 Serial CLKIN/DTR for
asynchronous communication
CLKIN IN
PF4/TXD1 24 Serial CLKREQ for asynchronous
communication
CLKREQ OUT
PF5/RXD1 25 Serial CTS for asynchronous
communication
CTS IN
PF6/CTS1/
SCLK1
26 Serial IF_DET for asynchronous
communication
IF_DET IN
DVCC 27 VCC
NMI 28 VCC connection VCC IN
P86/WAIT 29 HCTS HCTS IN
AM0 30 CPU mode setting (fixed to "1")
CLK 31 Not used NC
TEST0 32 Not used (GND fixed)
TEST1 33 Not used (GND fixed)
CLVSS 34 VSS
CLVCC 36 VCC
DVSS 37 GND
X1 38 9.83 MHz
X2 39 9.83 MHz
AM1 40 CPU mode setting (fixed to "0")
RESET 41 Hard reset RESET
WDTOUT 42 Abnormal detect (used by GA) TIMI
DVCC 43 VCC
PB0/CAS1 44 LED_ERROR LED_ERROR OUT On Off
PB1/UCAS1 45 LED_SLIP LED_SLIP OUT On Off
TableD-7 CPU terminals and functions
Port (Terminal) Pin Description Circuit Signal I/O I/O Definition
Name No. Name
HL
