I-8 Printer Handling Rev. A
Confidential
Note:
Because of variations in paper roll cores, it is not possible for the detector to measure exactly the length of
paper left on the roll when the detector is triggered.
If you want more paper left when the detector is triggered, change the setting, as described
below.
1. Open the printer cover, and remove the paper roll.
2. Loosen the adjusting screw with a coin, and carefully move the detecting lever up.
Figure I-12 Adjustment screw and detecting lever
3. Tighten the adjusting screw, and check to be sure that the detecting lever moves freely.
4. Replace the paper roll.
Using the Control Panel
Most of the functions of this printer are governed by software, but you can monitor the printer’s
status by looking at the lights on the control panel and for some procedures you will use the
buttons.
Figure I-13 Control panel
adjusting
screw
detecting
lever
