Rev. A Product Overview Appendix D-81
TM-H6000/H6000P Service Manual
Confidential
Receipt Unit
Printing Specifications
❏ Printing method Thermal line
❏ Dot density 180 dpi ✕ 180 dpi (dots per 25.4 mm)
❏ Print direction Uni-directional friction feed
❏ Printing width 72 mm, 512 dot positions
❏ Printed digits Font A: 42 digits
Font B: 56 digits
❏ Space between characters Font A: 0.28 mm (2 dots)
Font B: 0.28 mm (2 dots)
Can be set by command
❏ Printing speed Target max. 44 LPS(1/8 inch conversion)
(at 24V, 31°C, density level 2)
Max. 140 mm/sec (approx. 5.5 inches/sec)
Automatically changed over, depending on voltage
received by printer and head temperature conditions.
❏ Paper feed rate Approx. 140 mm/sec (approx. 5.5 inches/sec) (for
continuous paper feed)
❏ Carriage return 4.23 mm (1/6 inch) (default)
Can be set by command
Character Specifications
❏ Character type
❏ Character configuration
TableD-31 Type of characters
Characters Specifications
Alphanumeric Characters 95
Expansion Graphics 128
✕
8 pages (including one blank page)
International Characters 37
TableD-32 Character configuration
Font Specifications
Font A 12
✕
24 (including 2 dot spaces [W])
Font B 9
✕
7 (including 2 dot spaces [W])
To Next Page
