Epson TM-H6000 Service Manual

Rev. A Product Overview Appendix D-79
TM-H6000/H6000P Service Manual
Confidential
Slip Unit
Printing Specifications
❏ Printing method Serial impact dot matrix
❏ Head wire arrangement 9 x 1 row, wire pitch of 0.353 mm (1/72 inch)
❏ Printing direction Bidirectional printing at shortest distance
❏ Print speed Approx. 4.6 LPS (For 40 digits, 17.8 CPI printing:Normal
mode)
(LPS: Lines Per Second; CPI: Characters Per Inch)
❏ Printed lines/character spacing
Character Specifications
❏ Type of characters
❏ Character Configuration Font A 5 ✕ 9 (270 dots in horizontal direction)
Font B 7 ✕ 9 (540 dots in horizontal direction)
❏ Character Dimensions Defaults Font A
TableD-25 Character dimensions, printed digits, characters per inch
Character
Configuration
W x H
Character
Dimensions
W x H (mm)
Dot Spacing
Between
Characters
Printed Digits
(CPL)
Characters Per
Inch (CPI)
Font A 5
×
91.56
×
3.1 1 dot 45 13.3
Font B 7
×
91.24
×
3.1 2 half dots 60 17.8
TableD-26 Type of characters
Type of Characters Number of Characters
Alphanumeric 95
Expansion Graphics 128 x 8 (table) characters (including blank pages)
International Characters 37
TableD-27 Character dimensions, printed digits, characters per inch
Character
Configuration
W x H
Character
Dimensions
W x H (mm)
Dot Spacing
Between
Characters
Printed Digits
(CPL)
Characters Per
Inch (CPI)
Font A 5
×
91.56
×
3.1 1 dot 45 13.3
Font B 7
×
91.24
×
3.1 2 half dots 60 17.8
