Appendix J
Screw Types
Figure J-1 Screw configuration
Table J-1 Screw types
Head (top) Head (side) Body Washer (assembled)
C (Cross) P (Pan)
B (Bind)
C (Cup)
S-tite
B-tite
P-tite
T-B
(S) (Spring lock washer)
(S-P1)/(S-P2)/(S-P3)/(S-P4)
(Spring lock washer + plain
washer )
(O) (Outside toothed lock
washer)
(P1)/(P2)/(P3)/(P4) (Plain
washer)
(O-P1) (Outside toothed
washer + plain washer)
Head (top)
Head (side)
Washer (assembled)
Body
