Epson TM-H6000 - DIP Switch Settings; Serial Interface Specifications

Rev. A Product Overview Appendix D-73
TM-H6000/H6000P Service Manual
Confidential
DIP Switch Settings
Serial Interface Specifications
There are two DIP switches, DIP switch 1 and DIP switch 2, which have different functions.
DIP Switch 1
BPS: Bits Per Second
TableD-18 DIP switch 1 settings
Switch No. Function ON OFF
1
Data receive error Ignored "?" printed
2
Receive buffer capacity 45 bytes 4 KB
3
Handshake XON/XOFF DTR/DSR
4
Bit length 7 bits 8 bits
5
Parity check Yes No
6
Parity selection Even Odd
7
Baud rate selection See table below
8
TableD-19 Baud rate selection
Transfer Rate Switch No.
[BPS] 7 8
4800 ON ON
9600 OFF ON
19200 ON OFF
38400 OFF OFF
