I-2 Printer Handling Rev. A
Confidential
Opening the Front Cover
You can open the front cover of the printer by using the tabs on each side of the cover.
Figure I-2 Opening the front cover
Installing or Replacing the Paper Roll
You need to install a paper roll even if you are using only the slip section of the printer.
Note:
Do not use paper rolls that have the paper glued or taped to the core because they might cause a paper jam.
1. To prevent data loss make sure that the printer is not receiving data.
2. Open the paper roll cover by lifting up the two tabs on the paper roll cover and then pushing
the cover back.
3. Remove the used paper roll core if there is one.
tab
To Next Page
