Appendix E-8 Parts List Rev. A
Confidential
Reference Number List
name for service manual name for price list Q’ty page Ref.#
screw(C.B.S-tite F,3X4) C.B.S-TITE F,3X4,F/ZN 5 F-1 101
screw(C.P.T-B,3X10) C.P.T-B SCREW,3X10,F/ZN 7 F-1 103
screw(C.C.,4X20) C.C.SCREW,4X20,F/ZN 1 F-1 104
screw(C.C.S-tite,3X6) C.C.S.SCREW M3X6 3 F-1 105
screw(C.B.S-tite F,3X6) C.B.S-TITEF,3X6,F/ZN 12 F-1 106
screw(C.P.S-tite(0),3X6) C.P.S-TITE.(0),3X6,F/ZN 9 F-1,3 107
screw(C.B.B-tite,4X12) C.B.B.SCREW,4X12,F/ZN 2 F-1 108
screw(C.B.B-tite,4X25) C.B.B.SCREW,4X25 F/ZN 2 F-1 109
Clamp CLAMP 1 F-1 110
IC cover IC COVER 1 F-1 111
Plain washer(4.2X1X12) PLAIN WASHER,4.2X1X12,F/ZN 2 F-1 112
Rubber insulator spacer SPACER,INSULATOR 2 F-1 113
Metallic insulator spacer INSULATOR SPACER 2 F-1 114
Caution seal SEAL,CAUTION 1 F-1 115
Connector plate (type AA) PLATE,CONNECTOR,AA 1 F-1 116
Rubber foot RUBBER FOOT 3 F-1 117
Lower case CASE,LOWER 1 F-1 118
Upper case CASE,UPPER 1 F-1 119
Front case CASE,FRONT 1 F-1 120
Ribbon cassette cover COVER,RIBBON CASSETTE 1 F-1 121
Main plate sub assembly PLATE,MAIN,SUBU ASSEMBLY 1 F-1 122
Thermal case CASE,THERMAL 1 F-1 123
Switch panel unit SWITCH PANEL UNIT 1 F-1 124
Thermal holder assembly HOLDER,THERMAL ASSEMBLY 1 F-1 125
Thermal sheet SHEET,THERMAL 1 F-1 126
Thermal frame FRAME,THERMAL 1 F-1 127
Strengthening plate PLATE,STRENGTHEN,B 1 F-1 128
Hook plate PLATE,HOOK 2 F-1 129
Thermal cushion CUSHION,THERMAL 2 F-1 130
Left thermal spring SPRING,THERMAL,L 1 F-1 131
Right thermal spring SPRING,THERMAL,R 1 F-1 132
Hook spring SPRING,HOOK 2 F-1 133
Thermal button BUTTON,THERMAL 2 F-1 134
Thermal mechanism cover COVER,THERMAL MECHANISM 1 F-1 135
Lower plate PLATE,LOWER 1 F-1 136
