Epson TM-H6000 - Appendix E Parts List; Alphanumeric List

Rev. A Parts List Appendix E-1
TM-H6000/H6000P Service Manual
Confidential
Appendix E
Parts List
Alphanumeric List
name for service manual name for price list Q’ty page Ref.#
Belt drive cap CAP,BELT DRIVE 2 F-4 602
Belt tension spring SPRING,BELT TENSION 1 F-4 628
Blade holder spring SPRING,BLADE HOLDER 1 F-6 521
Carriage assembly CARRIAGE ASSEMBLY 1 F-4 677
Carriage belt BELT,CARRIAGE 1 F-4 627
Carriage cover frame assembly FRAME,CARRIAGE COVER ASSEMBLY 1 F-2 681
Carriage drive pulley PULLEY,CARRIAGE DRIVE 1 F-4 631
Carriage drive transmission gear GEAR,CARRIAGE DRIVE TRANSMISSION 1 F-4 632
Carriage guide shaft SHAFT,CARRIAGE GUIDE 1 F-4 629
Carriage motor MOTOR,CARRIAGE 1 F-4 697
Carriage spring SPRING,CARRIAGE 1 F-4 610
Carriage transmission pulley PULLEY,CARRIAGE TRANSMISSION 1 F-4 630
Caution seal SEAL,CAUTION 1 F-1 115
Circuit board FFC FFC,CIRCUIT BOARD 2 F-1 209
Clamp CLAMP 1 F-1 110
Connector plate (type AA) PLATE,CONNECTOR,AA 1 F-1 116
Connector plate (type BA) PLATE,CONNECTOR,BA 1 F-1 A
Cover open detector lead wire LEAD WIER,COVER OPEN DETECTOR 1 F-6 543
Cover shaft SHAFT,COVER 2 F-6 524
Cover spring SPRING,COVER 2 F-6 523
Cover tube COVER TUBE 4 F-6 532
Crank shaft holder CRANK SHAFT HOLDER 2 F-3 694
Deceleration gear GEAR,DECELERATION 1 F-6 505
Earth wire assembly EARTH WIRE ASSEMBLY 1 F-1,3 203
Endorsement platen shutter SHUTTER,ENDORSEMENT PLATEN 1 F-3 654
E-ring(1.5) RETAINING RING TYPE-E(1.5) 1 F-6 538
E-ring(1.5) RETAINING RING TYPE-E(1.5) 2 F-3 684
E-ring(2) RETAINING RING TYPE-E(2) F/UC 2 F-6 539
E-ring(2) RETAINING RING TYPE-E(2) F/UC 4 F-4 685
E-ring(2.3) RETAINING RING TYPE-E (2.3) F/UC 2 F-2,3 689
E-ring(2.5) RETAINING RING TYPE-E(2.5) 1 F-6 501
