Appendix E-2 Parts List Rev. A
Confidential
E-ring(3) RETAINING RING TYPE-E(3)F/UC 11 F-2,3,5 686
E-ring(4) RETAINING RING TYPE-E(4) F/UC 2 F-5 687
E-ring(5) RETAINING RING TYPE-E(5) F/UC 2 F-3,4 688
Fixed blade FIXED BLADE 1 F-6 507
Form stopper FORM STOPPER 1 F-3 617
Form stopper shaft SHAFT,FORM STOPPER 1 F-3 618
Form stopper spring SPRING,FORM STOPPER 1 F-3 619
Frame cover COVER,FRAME 1 F-6 518
Frame plate PLATE,FRAME 1 F-6 517
Front case CASE,FRONT 1 F-1 120
Front cover detector assembly FRONT COVER DETECTOR ASSEMBLY 1 F-2 664
Front frame FRAME,FRONT 1 F-3 612
Front reinforcement frame FRAME,FRONT REINFORCE 1 F-3 611
Front seal SEAL,FRONT 1 F-1 141
Gear shaft SHAFT,GEAR 1 F-6 522
Gear train cover COVER,GEAR TRAIN 1 F-4 725
Guard tube GUARD TUBE 1 F-6 533
H.P. detector assembly H.P.DETECTOR ASSEMBLY 1 F-4 675
Head caution seal SEAL,CAUTION,HEAD 2 F-6 513
Hexagon lock screw (inch type) HEXAGON LOCK SCREW 2 F-1 144
Hexagon lock screw (millimeter type) HEXAGON LOCK SCREW 2 F-1 144
Hexagon nut(3) H.N.-1,3,F/ZN 1 F-6 537
Hook plate PLATE,HOOK 2 F-1 129
Hook spring SPRING,HOOK 2 F-1 133
IC cover IC COVER 1 F-1 111
Intermediate cable (type A) CABLE,INTERMEDIATE,A 1 F-4 698
Intermediate cable (type B) CABLE,INTERMEDIATE,B 1 F-4 699
Intermediate cable (type C) CABLE,INTERMEDIATE,C 1 F-4 700
Intermediate cable tube TUBE,CABLE INTERMEDIATE 1 F-4 728
Intermediate circuit board assembly INTERMEDIATE CIRCUIT BOARD ASSEMBLY 1 F-4 676
Intermediate circuit board cover COVER,INTERMEDIATE CIRCUIT BOAD 1 F-4 726
Intermit circuit board assembly INTERMIT CIRCUIT BOARD ASSEMBLY 1 F-6 527
Intermit circuit board cable CABLE,INTERMIT CIRCUIT BOARD 1 F-1 206
J/S change gear J/S CHANGE GEAR 1 F-2 692
J/S change spacer SPACER,J/S CHANGE 1 F-2 647
Lead wire (type A) LEAD WIRE,A 1 F-3 705
name for service manual name for price list Q’ty page Ref.#
