Rev. A Parts List Appendix E-3
TM-H6000/H6000P Service Manual
Confidential
Lead wire (type B) LEAD WIRE,B 1 F-3 706
Lead wire (type C) LEAD WIRE,C 1 F-3 707
Lead wire (type D) LEAD WIRE,D 1 F-3 708
Lead wire (type E) LEAD WIRE,E 1 F-3 709
Lead wire (type F) LEAD WIRE,F 1 F-3 710
Lead wire (type G) LEAD WIRE,G 1 F-3 711
Lead wire (type H) LEAD WIRE,H 1 F-3 712
Lead wire (type I) LEAD WIRE,I 1 F-3 713
Lead wire (type J) LEAD WIRE,J 1 F-3 714
Lead wire (type K) LEAD WIRE,K 1 F-3 715
Lead wire (type L) LEAD WIRE,L 1 F-4 716
Lead wire (type M) LEAD WIRE,M 1 F-4 717
Lead wire (type N) LEAD WIRE,N 1 F-4 718
Lead wire (type U) LEAD WIRE,U 1 F-2 719
Lead wire (type V) LEAD WIRE,V 1 F-2 720
Lead wire (type W) LEAD WIRE,W 1 F-2 721
Left frame FRAME,LEFT 1 F-6 515
Left thermal spring SPRING,THERMAL,L 1 F-1 131
Lever coil mounting plate sub assembly MOUNTING PLATE,LEVER COIL SUB
ASSEMBLY
1 F-3 667
Lever drive coil (type A) COIL,LEVER DRIVE,A 1 F-3 620
Lever drive coil (type B) COIL,LEVER DRIVE,B 1 F-3 621
Lever drive motor assembly MOTOR,LEVER DRIVE ASSEMBLY 1 F-3 659
Lever drive motor detector plate DETECTOR PLATE,LEVER DRIVE MOTOR 1 F-3 613
Lever drive shaft assembly LEVER DRIVE SHAFT ASSEMBLY 1 F-3 665
Lever drive shaft gear GEAR,LEVER DRIVE SHAFT 1 F-3 616
Lever drive transmission gear GEAR,LEVER DRIVE TRANSMISSION 1 F-3 615
Lever motor reduction gear GEAR,LEVER MOTOR REDUCTION 1 F-3 614
Lever motor T.P. detector assembly LEVER MOTER T.P. DETECTOR ASSEMBLY 1 F-3 672
Lower case CASE,LOWER 1 F-1 118
Lower plate PLATE,LOWER 1 F-1 136
Main circuit board assembly (for M-U675) MAIN CIRCUIT BOARD ASSEMBLY (FOR M-
U675)
1 F-3 673
Main circuit board assembly (for TM-H6000/
H6000P)
MAIN CIRCUIT BOARD ASSEMBLY (FOR TM-
H6000/H6000P)
1 F-1 201
Main plate sub assembly PLATE,MAIN,SUBU ASSEMBLY 1 F-1 122
Manual cutter MANUAL CUTTER 1 F-6 530
Mechanism assembly (M-U675, type AB) MECHANISM ASSEMBLY,AB (M-U675) 1 F-1 600
name for service manual name for price list Q’ty page Ref.#
To Next Page
