Appendix D-84 Product Overview Rev. A
Confidential
Overall Specifications
Internal Buffer
Electrical Specifications
❏ Operating voltage +24 VDC ± 10% (Optional power source: PS-170)
Ripple voltage 300 m Vpp or less (when equipped with
MICR)
❏ Current Consumption (at 24V, excluding drawer kick drive)
Environmental Specifications
❏ Temperature Operating: 5 45°C
Storage: -10 50°C (excluding paper, ribbon)
❏ Humidity Operating: 10 90%RH
Storage: 10 90%RH (excluding paper, ribbon)
TableD-38 Internal buffer capacity
Buffer Capacity
Receive Buffer 45 bytes or 4 KB, selected by DIP switch
Download Buffer
(For download characters/download bit
images)
For receipts: 12 KB
For slips: Approx. 3 KB
Macro Buffer 2 KB
NV Bit Image Storage Area 384 KB
User NV Memory 1 KB
TableD-39 Current consumption
Mode Current Consumption
Operation Slips Average: Approx. 1.7 A (printing of all font A (alphanumeric digits)
Peak: Approx. 5.5 A
Receipts Average: Approx. 1.8 A (printing of all font A (alphanumeric digits)
Peak: Approx. 7.7 A
Standby Average: Approx. 0.2 A
